The ship-borne radar reconnaissance and jamming system can intercept and analyze enemy radar signals in real time, accurately locate threat sources. By means of active jamming, deception and other measures, it disrupts enemy detection, reduces their combat effectiveness, and enhances the ship's battlefield survival and operational command capabilities. It is a key equipment for maritime defense.

a)Reconnaissance Frequency Band: 0.8–40 GHz;
b)Jamming Frequency Bands: 6–18 GHz, 32–37 GHz;
c)Spatial Coverage:Horizontal: 360°,Vertical: -15°–45°;
d)Receiver Sensitivity: Better than -70 dBm;
e)Jamming Methods: Noise jamming, deceptive jamming, combined jamming;
f)Multi-Target Jamming Capability: 4 targets per side (port and starboard);
g)Minimum Jamming Range (Typical RCS: 2,000 m²):
                                                       For anti-ship terminal guidance radar: 4 km,
                                                       For airborne fire control radar: 100 km.
